Rpm Reducer Gearbox White 300 - 900rpm High Torque Machinery Gearbox 1084*420*452mm Dimension For Lab

Product Details

Place of Origin: CHINA

Brand Name: ZHITIAN

Model Number: SHTD35N

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: consult with

Packaging Details: Wooden Box

Delivery Time: 30-60 days

Payment Terms: L/C, T/T

Supply Ability: 50 Pieces/Month

Get Best Price
Highlight:

twin screw gearbox

,

extruder gearbox

Material:
Cast Iron
Color:
Red Or White
RPM Speed:
300-900r/min
Power:
18.5-60kw
Torque:
286-318N.M
Packaging:
Wooden Box
L*W*H:
1084*420*452MM
Weight:
380KG
Torque Grade:
10.9-11.79T/A3
Material:
Cast Iron
Color:
Red Or White
RPM Speed:
300-900r/min
Power:
18.5-60kw
Torque:
286-318N.M
Packaging:
Wooden Box
L*W*H:
1084*420*452MM
Weight:
380KG
Torque Grade:
10.9-11.79T/A3
Rpm Reducer Gearbox White 300 - 900rpm High Torque Machinery Gearbox 1084*420*452mm Dimension For Lab



SHTD35N White 300-900rpm High Torque Gearbox For Lab Use Machine


Quick Details

Product Name:SHTD35N White 300-900rpm High Torque Gearbox For Lab Use Machine
Material: Cast Iron
Color: Red or White
Exprience:20 years
Packaging: Wooden Box
Lead Time: 30-60 days



Rpm Reducer Gearbox White 300 - 900rpm High Torque Machinery Gearbox 1084*420*452mm Dimension For Lab 0

Adopting latest standard ISO1328,the precision of cylindrical gear of spherical involute, and combining our long term experience and specialty of twin-screw extruders, SHT gearboxes are meticulously designed with top advanced designing ideas in the world for co-orientated rotating twin-screw extruders, with entirely independent Intellectual Property Rights.
The gears are made of carburizing steel of high-strength alloy of good quality by carburizing and quenching for teeth, of which all the gear grinding processes are finished by imported gear grinding machines. Gear parameters are optimized and specially designed for the characteristics of twin-screw extruders, reducing stress concentration on root of gear and improving gear surface conditions. We have improved gear intension of flexural fatigue, fatigue strength and ratio of wide diameter. We have also adopted the latest designing idea and technology of heating treatment for the structure of gears, thereby ensured gears from uniformity of precision and strength.

Key Features

---Solid and optimized structure minimizes vibration.
---High torque and high output speed rate design.
---Precision gear grinding to keep operation noise very low.
---Forced lubrication and cooling filter system to ensure excellent heat dissipation.
---All bearings are sourced from global recognized brands.







SHTDN Twin Screw Extruder Gearbox Parameters




SHTDN Gearbox Power&Torque Table
Model CD(MM) Torque Grade(T/A3) RPM 300r/min RPM 400r/min RPM 500r/min RPM 600r/min RPM 800r/min RPM 900r/min
SHTD20N 18 <13 --- --- --- 7.5kw 11kw ---
SHTD25N 22 <13 --- --- 11kw 15kw 18.5kw 22kw
SHTD30N 26 <13 --- --- --- 22kw 30kw 37kw
SHTD35N 30 <13 18.5kw 22kw 30kw 37kw 50kw 60kw
SHTD40N 34.5 <13 30kw 45kw 55kw 65kw 90kw 90kw
SHTD50N 42 <13 55kw 75kw 90kw 110kw 132kw 160kw
SHTD52N 43 <13 55kw 75kw 90kw 110kw 132kw 160kw
SHTD58N 48 <13 90kw 110kw 132kw 160kw 220kw 250kw
SHTD65N 52 <13 110kw 132kw 160kw 220kw 280kw 315kw
SHTD75N 60 <13 160kw 220kw 250kw 315kw 450kw 500kw
SHTD85N 67.8 <13 220kw 315kw 400kw 500kw 600kw 650kw
SHTD95N 78 <13 350kw 450kw 550kw 650kw 900kw 1000kw
SHTD110N 92 <13 560kw 710kw 900kw 1000kw --- ---
SHTD125N 100 <13 800kw 1000kw 1250kw 1400kw --- ---
SHTD135N 110 <13 1000kw 1400kw 1600kw 2000kw --- ---
SHTD150N 120 <13 1320kw 1750kw --- --- --- ---



Production Process


NO.1


Workblank

NO.2


Rough Machining

NO.3


Finish Machining

NO.4


Gearbox Inspection

NO.5


Assemble

NO.6



Delivery


FAQ

How long does it take to get my products since I paid for them?
---According to yout order quantity,we will give you a reasonable delivery date.

Can I get the warranty of one year for free?
---If you need the warranty,you should pay for it.If not,do not worry ,we have confidence in our products.

How is your after-sale service?
---You will get our help in time as long as you find something wrong about our produces.Believe us,you deserve the best.

Are you responsible for the assembly?
---We will provide this service at your requst.
