Detailed Product Description
Name: Twin Screw Extruder Parts Feature: Simple Manufacture
Material: Cast Iron Color: Red Or White
Power: 500KW-2100KW Torque Grade: 16-18 Torque
Application: Twin Screw Extruder Packaging: Wooden Box
Center Distance: 78mm
High Light:

SHE conical twin screw barrel

,

95mm conical twin screw barrel

,

Cast Iron extruder barrel screw

New 16-18 Torque Cast Iron 95mm SHE Center Distance 78 Twin Screw Extruder





SHE Twin Screw Extruder Gearbox Introduction



Twin Screw Gearbox adopting latest standard ISO1328,the precision of cylindrical gear of spherical involute, and combining our long term experience and specialty of twin screw extruder, SHE gearboxes are meticulously designed with top advanced designing ideas in the world for co-orientated rotating twin screw extruder, with entirely independent Intellectual Property Rights.
The gears are made of carburizing steel of high-strength alloy of good quality by carburizing and quenching for teeth, of which all the gear grinding processes are finished by imported gear grinding machines. Gear parameters are optimized and specially designed for the characteristics of twin screw extruder, reducing stress concentration on root of gear and improving gear surface conditions. We have improved gear intension of flexural fatigue, fatigue strength and ratio of wide diameter. We have also adopted the latest designing idea and technology of heating treatment for the structure of gears, thereby ensured gears from uniformity of precision and strength.



16-18 Torque Cast Iron 95mm SHE Conical Twin Screw Barrel 016-18 Torque Cast Iron 95mm SHE Conical Twin Screw Barrel 1

Features:

----Double drive design enables the B axis to be driven by two gears without increasing the tooth width.

----Optimal structure and complex assembly lead to the cost rise.

----All bearings are sourced from global recognized brands,so output torque is more stable.

----The gearbox improves production efficiency and increases the service life.





SHE Twin Screw Extruder Gearbox Parameters



SHE95 Gearbox Power&Torque Table
Model RPM(r/min) Power(kw) Torque Grade(T/A3) CD(mm)
SHE95 300 550 16-18 78
400 710 16-18
500 850 16-18
600 1000 16-18
800 1400 16-18
900 1600 16-18
1200 2100 16-18
